| 品牌介紹：a global leader in the design, manufacturing, and distribution of RF, IF, and microwave components and integrated modules covering the DC to 40 GHz band, for commercial, industrial, space, and military applications, including: WiMax, CATV, Cellular Wireless, RFID, Medical Equipment, Test Equipment, Receivers, Transmitters Aerospace, Mil-Spec and Satellite applic -ations. | |||||||
MODEL NUMBER | CONNECTOR TYPE
| FREQUENCY RANGE(GHZ) | VSWR(:1) | IMPEDANCE | CASE STYLE/OUTLINE DRAWING | |||
CONN1 | CONN2 | LOW | HIGH | |||||
35F-35F50+ | 3.5mm-Female | 3.5mm-Female | DC | 34 | 1.07 | 50 | DJ1733 | |
35F-35F50+ | 3.5mm-Female | 3.5mm-Female | DC | 34 | 1.07 | 50 | DJ1734 | |
NF-BM50+ | N-Female | BNC-Male | DC | 2 | 1.15 | 50 | DJ1011 | |
NF-NF50+ | N-Female | N-Female | DC | 6 | 1.20 | 50 | DJ1092 | |
NF-SM50+ | N-Female | SMA-Male | DC | 18 | 1.20 | 50 | DJ826 | |
NF-SF50+ | N-Female | SMA-Female | DC | 18 | 1.20 | 50 | DJ827 | |
NFFL-SF50+ | N-Female | SMA-Female | DC | 18 | 1.2 | 50 | DJ1808 | |
NM-SF50+ | N-Male | SMA-Female | DC | 18 | 1.25 | 50 | DJ825 | |
NM-SM50+ | N-Male | SMA-Male | DC | 18 | 1.20 | 50 | DJ824 | |
SF-35M50+ | SMA-Female | 3.5mm-Male | DC | 26.5 | 1.1 | 50 | DJ1735 | |
SF-BF50+ | SMA-Female | BNC-Female | DC | 2 | 1.20 | 50 | DJ1025 | |
SF-BM50+ | SMA-Female | BNC-Male | DC | 2 | 1.20 | 50 | DJ1023 | |
SF-MOK50+ | SMA-Female | SMA-Male Quick connect | DC | 18 | 1.25 | 50 | DJ836 | |
SF-SF50+ | SMA-Female | SMA-Female | DC | 18 | 1.25 | 50 | DJ952 | |
SF-SM50+ | SMA-Female | SMA-Male | DC | 18 | 1.28 | 50 | DJ836 | |
SFFL-SF50+ | SMA-Female | SMA-Female | DC | 18 | 1.13 | 50 | DJ1821 | |
SM-BM50+ | SMA-Male | BNC-Male | DC | 2 | 1.20 | 50 | DJ1022 | |
SM-BF50+ | SMA-Male | BNC-Female | DC | 2 | 1.20 | 50 | DJ1024 | |
SM-SM50+ | SMA-Male | SMA-Male | DC | 18 | 1.30 | 50 | DJ951 | |
